• YWF(K)Ø300-Z
  • YWF(K)Ø300-Z
  • YWF(K)Ø300-Z
  • YWF(K)Ø300-Z

Description

Product Characteristic

  • Motor technology: AC Outer rotor
  • Mode of Operationc: S1
  • Protection Class: IP54
  • Insulation Class: B/F
  • Bearings: Maintenance-free ball bearings
  • Blades Material: Cold rolled sheet steel
  • Blades count: 5
  • Air direction: seen on the leads

Model Voltage (V) Frequency (Hz) Input Power (W) Current (A) Air Volume (m³/h) Speed (r/min) Capacitor (μF) Noise [dB(A)] Max Environmental Temperature (℃) Weight (Kg)
YWF(K)4E300-Z 230 50/60 90/115 0.38/0.48 1900/2100 1370/1500 3 55/60 65 3.2
YWF(K)4D300-Z 380 50/60 95/120 0.26/0.24 1950/2150 1400/1600 --- 55/60 65 4.0
