• YWF(K)Ø250-Z
  • YWF(K)Ø250-Z
  • YWF(K)Ø250-Z
  • YWF(K)Ø250-Z

Description

Product Characteristic

  • Motor technology: AC Outer rotor
  • Mode of Operationc: S1
  • Protection Class: IP54
  • Insulation Class: B/F
  • Bearings: Maintenance-free ball bearings
  • Blades Material: Cold rolled sheet stee
  • Blades count: 5
  • Air direction: seen on the leads

Model Voltage(V) Frequency(Hz) input Power(W) Current(A) Air Volume(m³/h) Speed(r/min) Capacitor(μF) Noise[dB(A)] Max Environmental Temperature(℃) Weight(Kg) A B
YWF(K)2E250-Z 230 50 180 0.78 1800 2500 4 68 65 3.0 102 134
YWF(K)4E250-Z 230 50/60 50/65 0.22/0.29 1000/1150 1380/1530 1.5 50/55 75 2.5 94 126
YWF(K)4D250-Z 380 50/60 60/70 0.13/0.15 1000/1150 1350/1550 --- 50/55 75 2.7 94 126
