Home > All Collections > AC Axial Fans > AC Axial fans Ø200 > YWF(K)Ø200-Z-S5A
  • YWF(K)Ø200-Z-S5A
  • YWF(K)Ø200-Z-S5A
  • YWF(K)Ø200-Z-S5A
  • YWF(K)Ø200-Z-S5A
  • YWF(K)Ø200-Z-S5A
  • YWF(K)Ø200-Z-S5A

YWF(K)Ø200-Z-S5A

GET A QUOTE
Add to Quote List View Quote List
  • YWF(K)Ø200-Z-S5A
  • YWF(K)Ø200-Z-S5A
  • YWF(K)Ø200-Z-S5A

Description

Product Characteristic

  • Motor technology: AC Outer rotor
  • Mode of Operationc: S1
  • Protection Class: IP54
  • Insulation Class: B/F
  • Bearings: Maintenance-free ball bearings
  • Blades Material: Cold rolled sheet steel
  • Blades count: 5
  • Air direction: Suction, seen on the leads

Model Voltage (V) Frequency (Hz) Input Power (W) Current (A) Air Volume (m³/h) Speed (r/min) Capacitor (μF) Noise [dB(A)] Max Environmental Temperature (℃) Weight (Kg)
YWF(K)2B200-Z-S5A 115 60 140 1.1 940 3100 12 67 65 2.2
